spiral duct forming machine
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
Product Description
Hvac duct machine , Spiral round duct machine , spiral tubeformer
Feature:
Special mould for various duct diameters , easy to change and adjust, no needs crane or too much manpower
Large diameter range
High speed saw cutting and plasma cutting system
Light and small , suitable for site work .
Technical information for SBJX-2000A
| Thickness of material | Galvanized steel :0.5-2.0mm |
| Stainless steel | 0.5-1.2mm |
| Power | 11.5KW |
| Width of material | Standard :137mm |
| Customized | 134mm/140mm/178mm |
| Diameter | 100-1500mm |
| Feeding speed | 1-38m/min |
| Machine size | 3200*2050*2100mm |
| Weight | 2200KG |
| Cutting system | Saw cutting /Plasma cutting |
Feature
Special mould for various duct diameters , easy to change and adjust, no needs crane or too much manpower
Large diameter range
High speed saw cutting and plasma cutting system
Light and small , suitable for site work .
