Galvanized sheet pneumatic spot welding machine
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
Product Description
|
Model |
FN-35 |
FN-55 |
FN-75 |
FN-100 |
|
Sheet Thickness |
0.4-1.0mm |
0.4-1.2mm |
0.4-1.5mm |
0.4-2.0mm |
|
Max Power |
45KVA |
55KVA |
75KVA |
110KVA |
|
Max Electric |
6200A |
11000A |
16000A |
26000A |
|
Max Air Pressure |
400KGF |
600KGF |
1000KGF |
1000KGF |
|
Cooling Water |
6L/min |
6L/min |
8L/min |
8L/min |
|
Welding Arm Length |
600mm |
600mm |
600mm |
600mm |
|
Stroke |
80mm |
80mm |
80mm |
80mm |
|
Welding Speed |
0.5-3m/min |
0.5-3m/min |
0.5-3m/min |
0.5-3m/min |
|
Weight |
328KG |
378KG |
428KG |
478KG |
|
Dimension |
1800x610x1930mm |
1800x610x1930mm |
1800x610x1930mm |
1800x610x1930mm |
