Air Duct Production Line Rectangular Air Duct Production Line Three

description1
Zipper closure 1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout
Product Description

I. Advantage of Products:

·  The latest design can resolve the problems like getting struck, too many repairs form roll-shearing displacements lock machine.

·     The three-line bending function can crimp narrow edges and stably process 0.5-1.2mm galvanized sheet to avoid wasting.

·  Mechanical arm clutching, locating and transferring platform

·  Displacement lock machine

·  Line 3 host+ Single rack

II. Function:

· It's mainly for uncoiling, levelling, beading, punching, lockforming. Because of its small space requirement and easy to install and operate the machine can upgrade to "super line 4".

III. Performance Features:

· All the rolling reels are made of bearing steel so that the lifetime prolongs by more than 5 times.

· Under the material-saving mode of CNC system, machine can withdraw material automatically after finishing tasks.

· With production memory functions, the production orders can be tracked and checked.

IV. Main Import Configuration:

· · MITSUBISHI HMI Display And PLC

· · MITSUBISHI Frequency Converter

· · Japan NEMICON Inverter

· · Taiwan Hydromax Pump

·   Taiwan High Temperature Resistant Tubing

V. Basic Configuration:

· One electric coil cradles, 2 material trays (5-7t each roll)

· One rack

· One host (line3 host)

· One mechanical arm clutching, locating and transferring platform

· One displacement type locking machine

· One set of computer controlling system

​Model No.

Max Coil Width

Thickness Range

Speed

Shearing Tolerance

Diagonal Tolerance

SBJX-LINE3-1.2x1300

1300mm

0.4-1.2mm

0-18m/min

±0.5mm

±0.5mm

SBJX-LINE3-1.2x1600

1600mm

0.4-1.2mm

0-18m/min

±0.5mm

±0.5mm
